Engine and transmission
Displacement: 600.00 ccm (36.61 cubic inches)
Engine type: In-line four
Stroke: 4
Power: 96.55 HP (70.5 kW))
Torque: 63.10 Nm (6.4 kgf-m or 46.5 ft.lbs) @ 6400 RPM
Bore x stroke: 65.5 x 44.5 mm (2.6 x 1.8 inches)
Fuel system: Injection
Fuel control: DOHC
Ignition: TCI (digital)
Lubrication system: Wet sump
Cooling system: Liquid
Gearbox: 6-speed
Clutch: Wet, multiple-disc
More details Consult a Yamaha repair manual.
Physical measures
Weight incl. oil, gas, etc: 208.0 kg (458.6 pounds)
Seat height: 795 mm (31.3 inches) If adjustable, lowest setting.
Overall length: 2,095 mm (82.5 inches)
Ground clearance: 145 mm (5.7 inches)
Wheelbase: 1,440 mm (56.7 inches)

Chassis and dimensions
Trail: 98 mm (3.8 inches)
Front suspension: Telescopic forks
Front suspension travel: 130 mm (5.1 inches)
Rear suspension: Swingarm
Rear suspension travel: 130 mm (5.1 inches)
Front tyre dimensions: 120/70-ZR17
Rear tyre dimensions: 180/55-ZR17
Front brakes: Double disc. ABS
Front brakes diameter: 298 mm (11.7 inches)
Rear brakes: Single disc. ABS
Rear brakes diameter: 245 mm (9.6 inches)

Other specifications
Fuel capacity: 19.40 litres (5.13 gallons)
Oil capacity: 3.40 litres (0.22 quarts)
