Engine and transmission
Displacement: 292.00 ccm (17.82 cubic inches)
Engine type: Single cylinder
Stroke: 4
Fuel system: Injection
Fuel control: SOHC
Ignition: Electronic inductive discharge
Starter: Electric
Cooling system: Liquid
Gearbox: Automatic
Transmission type
final drive: Belt
Clutch: Dry centrifugal type
Physical measures
Dry weight: 174.0 kg (383.6 pounds)
Overall length: 2,100 mm (82.7 inches)
Overall width: 780 mm (30.7 inches)
Wheelbase: 1,530 mm (60.2 inches)
Chassis and dimensions
Frame type: Double cradle trellis made of high-strength steel tubes
Front suspension: Telescopic hydraulic fork with ö 35 mm shafts;
Front suspension travel: 94 mm (3.7 inches)
Rear suspension: Double hydraulic shock absorber with four-position spring preload
Rear suspension travel: 76 mm (3.0 inches)
Front tyre dimensions: 120/70-14
Rear tyre dimensions: 140/60-14
Front brakes: Single disc. Stainless steel disk, two-piston floating caliper
Front brakes diameter: 260 mm (10.2 inches)
Rear brakes: Single disc. Stainless steel disk, caliper with two opposite pistons
Rear brakes diameter: 240 mm (9.4 inches)
Exhaust system: Closed loop system with lambda sensor and three-way catalytic converter in exhaust pipe
